Technical specification | |
---|---|
Riveting capacity R=40 kg/mm² | Ø2÷12 mm |
Micrometric lift control | 0÷40 mm |
Height of the working space | 60÷200 mm |
Workspace | 270x285 mm |
"T" groove | 10x22 mm |
Location hole for tools - diameter | 30 mm |
Tool diameter | 12-14 mm |
Tool length A | 58 mm |
Tool length B | 100 mm |
Tool length C | 76 mm |
Input power | 400 V - 50 Hz |
Input power | 2÷6 bar |
Work pressure | 1÷6 bar |
Working time | 0,1÷9,9 s |
Total weight | 230 kg |
