Lobster AR2000SV
Lightweight riveting pliers with an excellent power-to-weight ratio.
- Shockless technology offers ergonomically correct operation to minimize the risk of cumulative trauma disorder
- Fastens rivets Ø 2.4 to 3.2 mm in all materials and Ø 4.0 outside stainless steel
- The integrated silencer reduces working noise and is more environmentally friendly
- Wear-resistant materials (high-strength polymer housing) ensure a long tool life
- The air hose can be attached to both sides of the riveter for greater flexibility of use
- Long stroke
- Integrated vacuum system for holding rivets and collecting mandrel
Rivet diameter | Al | St | A2 | Cu | CuNi |
2,4 |
x | x | x | x | x |
3,0 | x | x | x | x | x |
3,2 | x | x | x | x | x |
3,4 | x | x | x | x | x |
4,0 | x | x | |||
4,8 / 5,0 | |||||
6,0 | |||||
6,4 | |||||
7,8 |
Model | Dimension 1 | Dimension 2 | Dimension 3 | Dimension 4 | Dimension 5 |
---|---|---|---|---|---|
AR2000SV | 289mm | 240mm | 94mm | 62.0mm | φ19mm |
Model | AR-2000SV |
Stroke | 14 mm |
Air consumption (l/min) | 90 suction on |
Weight | 1,25 kg |
Diameter of the riveter nose | 19 mm |
Work pressure (MPa) | 0,5-0,6 |
Tensile | 4,8 kN |
Riveting range |
2,4/3,2 for all materials 4,0 except stainless steel |
Collets | Ultra S |
